DJ SERIER BEAM ERECTOR

1.Capacity: 50T-500T
2.Span: ≤40m
3.Lifting speed: 0-1.0m/min(No load),0-0.5m/min(Load)
4.Traveling speed:0-4.5m/min(No load),0-3.6m/min(Load)
5.Launching speed: 0-3.6m/min
6.Allowable slope: ≤3%（L），≤2%（T）
7.Curve radius: ≥300m
8.Power: 480Kw
9.Working class: A3/M4

Product Description:


DJ50130 IN SIHWA BRIDGE PROJECT, KOREA

〓 EQUIPMENT PROFILE

DJ Series Beam Erector is a bridge construction equipment developed by our company with independent intellectual property rights. It is used to erect a variety of prestressed reinforced concrete simple supported girders of 70 meters, 600 tons and below the highway. It is a single arm simple supported type, which can set up straight bridges, inclined bridges, and curved bridges.

In the same industry of bridge Erector, DJ Series Beam Erector is favored by the majority of users for its novel structure, wide range of application, light weight, convenient transportation and assembly, excellent performance, high degree of automation, and complete functions. The machine adopts simple Support guide through the hole, which is safe and flexible, and greatly reduces the Rear Support force on the beam surface when the Girder Lauching. It is especially suitable for beam construction under special conditions such as large slope and small curve.

DJ Series Beam Erector passed the new product identification of Hebei Province on May 16, 2002, and won the "Top Ten Excellent Invention Award" of Hebei Province in 2002. In 2003, it obtained the "National Key New Product" certificate issued by the Ministry of Science and Technology of China, the State Administration of Quality Supervision and Inspection, the Ministry of Commerce and other five ministries and commissions, and obtained a number of technical patents.

We've sold more than 600 units of this beam erector.

〓 PARAMETERS

No.	Item	Detail
1	Capacity	50T-500T
2	Span	≤70m
3	Lifting speed	0-1.0m/min(No load) 0-0.5m/min(Load)
4	Traveling speed	0-4.5m/min(No load) 0-3.6m/min(Load)
5	Launching speed	0-3.6m/min
6	Allowable slope	≤3%（L），≤2%（T）
7	Curve radius	≥300m
8	Power	150Kw
9	Working class	A3/M4

〓 PROJECT CASES


D32240 IN HANOI URBAN RAILWAY, VIETNAM	DJ BEAM ERECTOR IN KOCHI BRIDGE, INDIA

DJ48180 IN PADMA BRIDGE PROJECT, BANGLADESH	DJ40180 IN CHINA-LAOS RAILWAY PROJECT, LAOS

DJ50150 IN SEPASA PROJECT, MEXICO	DJ50160 IN SAN JOSE NORTH RING ROAD PROJECT, COSTA RICA

DJ50140 IN PREFAMOVIL PROJECT, MEXICO	DJ40100 IN METSOVITIKOS BRIDGE PROJECT, GREECE

DJ48180 IN KALLADY BRIDGE PROJECT, SRI LANKA	DJ40180 IN BINBO EXPRESSWAY PROJECT, CHINA

DJ48220 IN STEEL BOX GIRDER PROJECT, CHINA	DJ2168 IN CCECC PROJECT, NIGERIA

DJ40180 IN RAILWAY PROJECT, CHINA	DJ40180 IN CREC PROJECT, CHINA
